2026 Kioti CX2510HCB
Get in Touch
Description
2026 Kioti CX2510HCB
Features May Include:
Manual or Hydrostatic Transmission
- Infinite 2-range hydrostatic (HST) transmission for effortless control, twin pedals for intuitive forward and reverse movements, seamlessly adjusting speed without ever touching a clutch.
Convenient Features
- Features a comfortable suspension seat, single lever joystick, tilt wheel with power steering, rear PTO, adjustable 3-point hitch, illuminated dashboard, USB and power socket.
Open Station Platform
- Every control, every button, every lever falls effortlessly within reach, like an extension of your own will. This intuitive layout isn't just about luxury, it's about efficiency.
Single Lever Joystick
- The single lever joystick redefines front-loader operation. With a flick of your wrist, you command every movement, from raising the boom to lowering the bucket. A float position allows the bucket free flotation over the ground surface.
Info
Industry
Agriculture
Make
Kioti
Model
CX2510HCB
Trim
Base
Year
2026
MSRP
N/A
Category
Tractor
Subcategory
Compact
Specs
Warranty
Non-Commercial Application: 24 Months, Coverage: Parts & Labor | Rental and Commercial Application: The first to occur of 24 months of 1500 hours, Coverage: Parts & Labor
Engine
Model: 3A165LWH-U3 | Engine Manufacturer: KIOTI
Power/Horsepower
24.50 hp (18.30 kW)
Displacement
87 cu. in. (1,647 cc)
RPM
2,600 rpm
Fuel Type
Diesel
Fuel Capacity
6.60 gal (25 L)
Transmission
Hydrostatic | Shuttle: Hydrostatic | Main Gear: Hydrostatic | Travel Speeds Forward: 10 | Travel Speeds Reverse: 7 | Travel Speeds Minimum Speed: 0 mph (0 km/h) | Travel Speeds Maximum Speed: 10.70 mph (21.74 km/h) | Travel Speeds Min Reverse Speed: 0 mph (0 km/h) | Travel Speeds Max Reverse Speed: 7.46 mph (15.22 km/h)
PTO Type
Transmission | PTO Power: 18.80 hp (14 kW) | Rear Speed: 540 rpm | Mid Speed: 2,000 rpm
Brakes
Wet Disc Type
Clutch
Dry Single Stage
Steering
Hydrostatic Power Steering
Notes
Hydraulics - Pump: Gear | Hydraulics - Pump Capacity: 11.30 gpm (42.90 lpm) | Hitch - Type: Three Point | Hitch - Category: Category 1 | Hitch - Control Type: Position
Load Capacity
Hydraulics - Lift Capacity: 1,203 lb (546 kg) | Hitch - Lift Capacity: 1,203 lb (546 kg)
Length
Wth Hitch: 11 in (2,820 mm)
Width
49.40 in (1,256 mm) | Front Tread: 38.10 in (968 mm) | Rear Tread: 37.40 in (951 mm)
Wheelbase
59.80 in (1,520 mm)
Ground Clearance
13.40 in (340 mm)
Turning Radius
9 ft (2.75 m)
Weight
2,804 lb (1,272 kg)
Height
86.60 in (2,200 mm)
Tires
Agricultural - Front: 7.0-12 | Agricultural - Rear: 11.2-16 | Industrial - Front: 23-8.5-12 | Industrial - Rear: 12-16.5 | R14 - Front: 23-8.5-12 | R14 - Rear: 12-16.5 | Turf - Front: 23-8.5-12 | Turf - Rear: 33-12.5-16.5
