2026 Manitou Group MSI 50 ST5
Get in Touch
Description
2026 Manitou Group MSI 50 ST5
For years, many manufacturers have recognised the exclusive advantages of the MSI concept from MANITOU.
Equipped with large-diameter wheels at the front, this compact semi-industrial forklift excels on all terrains, both indoors and outdoors.
With crossing qualities, stability and manoeuvrability that are incomparable for its category, the MSI 50 is very versatile: handling long loads, storage/unstocking, loading/unloading (trucks, wagons...), and is used in a wide variety of sectors (oyster farming, food processing, timber industry...).
Info
Industry
Agriculture
Make
Manitou Group
Model
MSI 50 ST5
Trim
Base
Year
2026
MSRP
N/A
Category
Forklift
Subcategory
General
Specs
Fuel Type
Diesel
Notes
Operator type: Seated | Load center of gravity: 24 in | Load distance, centre of drive axle to fork: 28 in | Standard mast reference of the machine: FVD 37 | Forks section / width / length: 2 in x 6 in x 47 in | Fork carriage ISO 2328 (class/form): A/B 4A | Travel speed (laden / unladen): 13 mph-13 mph | Lifting speed (laden / unladen): 1 ft/s-1 ft/s | Lowering speed (laden / unladen): 2 ft/s-1 ft/s | Drawbar pull (Laden / Unladen): 3250 daN / 2471 daN | Gradeability (laden / unladen): 42 % / 26 % | Rated speed: 2200 rpm | Fuel consumption according to VDI cycle: 1 US gph | Type of drive control: Electronic | Working hydraulic pressure for attachments: 3336 PSI | Oil flow rate for attachments: 24 US gpm | Sound level at the driver's ear according to DIN 12 053: 81 dB
Load Capacity
11023 lb
Wheelbase
82 in
Weight
Service weight: 18563 lb | Weight on front axle (laden) / rear axle (laden): 25287 lb / 4299 lb | Weight on front axle (Unladen) / rear axle (Unladen): 7694 lb / 1087 lb
Tires
Pneumatic
Wheels
Dimensions of front wheels: 315/70 R22,5 KMAX S | Dimensions of rear wheels: 225/75 R15 XZM | Number of front wheels / rear wheels: 2 / 2 | Number of drive wheels: 2 | Front wheel gauge: 56 in | Rear wheel gauge: 45 in
Height
Seat height/stand height: 56 in | Height of overhead guard (cabin): 96 in | Height of towing bar (coupling height): 24 in
Length
180 in | Length to face of forks: 133 in
Width
68 in | Fork carriage width: 66 in | Aisle Width for pallets 1000 x 1200 crossways: 206 in
Ground Clearance
Ground clearance below mast: 7 in | Ground clearance at centre of wheelbase: 9 in
Turning Radius
116 in
Brakes
Service brake: Hydraulic
Transmission
Hydrostatic
Engine
Deutz / TCD 2,9L / Stage V
Power/Horsepower
75 Hp/55 kW
Cylinders
4 - 177 in³
