2026 Doepker Open End Tridem Triple Hopper 45 ft
Get in Touch
Description
2026 Doepker Open End Tridem Triple Hopper 45 ft
Building trailers since 1972 has allowed us to lead the industry with continuous industry changing designs. The open end bulker design was no exception. Delivering the first open end bulker the market had ever seen in 1997 changed everything, including the industry. Our design is so strong, it is backed by a 5 year 100% structural warranty. Our highly engineered design is so light, aluminum trailers with the same options are still trying to shed hundreds of kilograms to compete. Using very specific high value, stronger metals in combination with a unique engineered design ensures the longest lasting trailer on market. Many have tried to copy our legendary design, however none have succeeded. Since 2001, we have added sophisticated and proven finishes that we still continually test and re-formulate. One example is our application of unique and special blended 100% pure zinc to the complete steel outside designed to combat Canadian road contaminants. Many have tried to copy our legendary design, however none have succeeded. By having 3 hoppers underneath our trailer, the ability to get your legal payload to the tridem group based on our design is unmatched and proven. In addition, it allows the farming community to haul all 3 commodities in one trailer to make seeding a one person task when utilizing 2 dry fertilizers. This model is available for tandem drive and tri-drive trucks. Visit your local dealer to view and discuss all of the great and numerous Doepker advantages and options on this trailer.
Info
Industry
Trailer
Make
Doepker
Model
Open End Tridem Triple Hopper
Trim
45 ft
Year
2026
MSRP
N/A
Category
Semi Trailer
Subcategory
Hopper / Grain Trailer
Specs
Length
45 ft
Max Load
Capacity: 45 ft Model Approx 2138 cu ft
Dry Weight
Tare: 45 ft Model Approx 12,250 lbs to 12,900 lbs Dependant on Options
GVWR
45 ft Model Approx 37,500 kg
Notes
Impact Guard: Rear Impact Guard with Doepker Logo in ICC Panel | Mudflaps: Full Width at Landing Gear, Ahead of Brake Pots on 1st Axle, Mudflap on Back 2 Hoppers Optional: In Front of Brake Pots on All Axles and 3 Ahead of Back 2 Hoppers | Wiring Harness: Severe Duty Sealed Harness System | Custom Designed by Trucklite for our Light Packages | Tarp Opener: Long Crank at Rear | System: Michels Side Rolling: Select or Maximizer | Sealing Systems: Silicone on Inside Wall Seams and Slope Sheet Seams | Safety: Reflective Tape | Professional Cure System: Entire Trailer put in Heat Ovens for Optimal Paint Adhesion and Cure | Top Coat: PPG Urethane / Acrycote Systems - All Colors Available | Primer: PPG Epoxy Primer Inside and Out | Duraguard: Complete Undercarriage from Hoppers Down | Special Coatings: Pure Zinc on Complete Outside Top To Bottom | Blast: Completely Steel Shot Blasted | Rims: 22.5 or 24.5: Various Steel and Aluminum Options | Tow Hooks: Back of Trailer | Air System: Aluminum Air Tanks | Inline Air Filtration System Built into Glad hands | Air Gauge Box with Window | Slopes: 14 Gauge Plain Aluminum Slope Sheet and End Wall | Chute Cranks: D/S and C/S | Chute Lids: Self Cleaning Opening Past Hopper; Quick Detach | Hoppers: 14 Gauge Steel; Rack & Pinion Chutes 16 in X 24 in Openings; 22 in Ground Clearance on 22.5 Tires | Catwalks and Ladders: Aluminum on Outside; Alum / Steel on Inside | Landing Gear: Jost Magnum 2 Speed Sealed Unit | King Pin: 45 ft Model Set at 18 in with 1/4 in Coupler Plate
Walls
16 Gauge Steel Panel; 4 in Vertical Corrugations 45 ft Tridem Wall Height: 72 in (79 in Overall); 136 in to Top of Tarp Hood
Tires
Michelin or BF Goodrich
Suspension
System: Hendrickson Intraax AANT 23K LDA 15 in Air Ride - HXL5 Hendrickson Long Life Dressed Axle
Wheels
Seals: Federal Mogul | End: Cast Hub and Drum
Brakes
Abex 16 1/2 in x 7 in Extended Life | Spring Brake Pots: 30/30 TSE Omnibrake
Axles
Spread: 60 in Tridem; 77-1/2 in Track Width
Lights
Trucklite LED as per CMVSS with Side Signals
Fenders
Stoneguards at Front Trailer | 1/2 Round Fenders at Back of Trailer: Aluminum or Optional Stainless Steel
