2026 Doepker Open End Tridem Triple Hopper 46 ft 3 in
Get in Touch
Description
2026 Open End Tridem Triple Hopper 46 ft 3 in
Building trailers since 1972 has allowed us to lead the industry with continuous industry changing designs. The open end bulker design was no exception. Delivering the first open end bulker the market had ever seen in 1997 changed everything, including the industry. Our design is so strong, it is backed by a 5 year 100% structural warranty. Our highly engineered design is so light, aluminum trailers with the same options are still trying to shed hundreds of kilograms to compete. Using very specific high value, stronger metals in combination with a unique engineered design ensures the longest lasting trailer on market. Many have tried to copy our legendary design, however none have succeeded. Since 2001, we have added sophisticated and proven finishes that we still continually test and re-formulate. One example is our application of unique and special blended 100% pure zinc to the complete steel outside designed to combat Canadian road contaminants. Many have tried to copy our legendary design, however none have succeeded. By having 3 hoppers underneath our trailer, the ability to get your legal payload to the tridem group based on our design is unmatched and proven. In addition, it allows the farming community to haul all 3 commodities in one trailer to make seeding a one person task when utilizing 2 dry fertilizers. This model is available for tandem drive and tri-drive trucks. Visit your local dealer to view and discuss all of the great and numerous Doepker advantages and options on this trailer.
Info
Industry
Trailer
Make
Doepker
Model
Open End Tridem Triple Hopper
Trim
46 ft 3 in
Year
2026
MSRP
N/A
Category
Semi Trailer
Subcategory
Hopper / Grain Trailer
Specs
Length
4 ft 3 in for Tri-Drive Truck Application
Notes
Impact Guard: Rear Impact Guard with Doepker Logo in ICC Panel | Mudflaps: Full Width at Landing Gear, Ahead of Brake Pots on 1st Axle, Mudflap on Back 2 Hoppers Optional: In Front of Brake Pots on All Axles and 3 Ahead of Back 2 Hoppers | Wiring Harness: Severe Duty Sealed Harness System | Custom Designed by Trucklite for our Light Packages | Tarp Opener: Long Crank at Rear | System: Michels Side Rolling: Select or Maximizer | Professional Cure System: Entire Trailer put in Heat Ovens for Optimal Paint Adhesion and Cure | Top Coat: PPG Urethane / Acrycote Systems - All Colors Available | Primer: PPG Epoxy Primer Inside and Out | Duraguard: Complete Undercarriage from Hoppers Down | Special Coatings: Pure Zinc on Complete Outside Top To Bottom | Blast: Completely Steel Shot Blasted | Antilock Braking System: Meritor Wabco 2S2M (2 Sensors / 2 Modulators) | Rims: 22.5 or 24.5: Various Steel and Aluminum Options | Tow Hooks: Back of Trailer | Air System: Aluminum Air Tanks | Inline Air Filtration System Built into Glad hands | Air Gauge Box with Window | Slopes: 14 Gauge Plain Aluminum Slope Sheet and End Wall | Chute Cranks: D/S and C/S | Chute Lids: Self Cleaning Opening Past Hopper; Quick Detach | Hoppers: 14 Gauge Steel; Rack & Pinion Chutes 16 in X 24 in Openings; 22 in Ground Clearance on 22.5 Tires | Catwalks and Ladders: Aluminum on Outside; Alum / Steel on Inside | King Pin: 46 ft 3 in Model Set at 18 in with 3/8 in Coupler Plate for Tri-Drive Model | Capacity: 6 ft 3 in Model Approx 2122 cu ft | Landing Gear: Jost Magnum 2 Speed Sealed Unit
Dry Weight
Tare: 46 ft 3 in Model Approx 13,850 lbs to 13,500 lbs Dependant on Options
GVWR
46 ft 3 in Model Approx 43,000 kg
Walls
46 ft 3 in Tridem Wall Height: 76 in (83 in Overall); 144 in to Top of Tarp Hood
Tires
Michelin or BF Goodrich
Suspension
System: Hendrickson Intraax AANT 23K LDA 15" Air Ride - HXL5 Hendrickson Long Life Dressed Axle
Wheels
Seals: Federal Mogul | End: Cast Hub and Drum
Brakes
Abex 16 1/2 in x 7 in Extended Life
Axles
Spread: 60 in Tridem; 77-1/2 in Track Width
Lights
Trucklite LED as per CMVSS with Side Signals Optional: Various Custom Packages and Designs Available
Fenders
Stoneguards at Front Trailer
